Professional Factory All Dielectric Self-Supporting G652D ADSS 4 Core Cable Adss Optic Fiber

Brand Name : JQ\OEM

Model Number : ADSS

Certification : CE/ISO9001

Place of Origin : Guangdong,China

MOQ : 1kilometer

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 80000 kilometers per month

Delivery Time : 2-4 days

Packaging Details : Wooden Drum

Fiber Core : 2-288 Core

Jacket : PE

Storage/Transport temperature range : -40℃ to +60℃

Number of Conductors : ≥ 10

Package : Wood Drum

MOQ : 1KM

Strength Member : FRP

Contact Now

Professional Factory All Dielectric Self-Supporting G652D ADSS 4 Core Cable Adss Optic Fiber

Products Description

Fiber parameter

Item		Unit	Specification
Fiber Type			G.652D
Mode field diameter	1310nm	mm	9.2±0.4
Mode field diameter	1550nm	mm	10.4±0.8
Cladding diameter		mm	125.0±1
Cladding non-circularity		%	≤1.0
Core/cladding concentricity error		mm	≤0.5
Coating diameter		mm	245±5
Coating non-Circularity		%	≤6.0
Coating/cladding concentricity error		mm	≤12.0
Cable cut-off wavelength		nm	≤1260
Attenuation Coefficient	1310nm	dB/km	≤0.36
Attenuation Coefficient	1550nm	dB/km	≤0.22
Proof stress level		kpsi	≥100

Apply to

messenger overhead

Why Choose Us !

Professional Factory All Dielectric Self-Supporting G652D ADSS 4 Core Cable Adss Optic Fiber

Product packaging

Packing :
Each single length of cable shall be reeled on Fumigated Wooden Drum suitable for long distance shipment.
Sealed by strong wooden battens.
At least 1 m of inside end of cable will be reserved for testing.

Total quantity is at least the ordered quantity


100% Wood Reel
100% wood reel , fumigation label, safe, environmentally friendly and can be recycled

Cable Rolling
Different dia of wood drum suit for different distance , from 2km to 5km

Solid Wood Package
The packaging is firm and can be applied to complex geographical environment construction

Payment

We usually use T/T

T/T deposit before production and balance when shipment.
